HDPE Moulded Butt Fusion Flange Stub End Wholesale

Home / Products / HDPE Fitting / Butt Fusion Fitting / HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
  • HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
  • HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
  • HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
  • HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
  • HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
  • HDPE Moulded Butt Fusion Flange Stub End For Water Pipe
Butt Fusion Fitting

HDPE Moulded Butt Fusion Flange Stub End For Water Pipe

Description
HDPE Flange Adapter, also called HDPE stub flange or HDPE stub end, is a cost-effective, easy to assemble, mechanical joint intended to connect HDPE pipe to any flange piping components (such as valves, pumps..etc) without the need for costly fusion equipment.
When joining to metal or to certain other piping materials, or if an HDPE pipe section capable of disassembly is required, an HDPE flange adaptor or HDPE stub flange is available. These items are designed so that one end matches the HDPE pipe for a butt fusion connection, and the opposite end contains a stub that provides structural support. By utilizing the addition of a steel backup ring, it permits bolting to a similar flanged end connection to another pipe, of various possible materials.
HDPE flange adaptor shall be assembled together with steel backup rings (G.I. backing rings). Steel bolts/nuts & rubber gaskets will be also requested.
NOTE: Gaohui has a lot of inventory for normal sizes and items, and will be delivering goods in a short time, of course, we have more experience in handling urgent orders.
CONTACT US
  • description
  • application
  • message to us
  • FAQ

Material

virgin raw material

Size

dn50mm-dn1200mm(outer diameter)

Pressure

SDR17 PN10, SDR13.6 PN12.5, SDR11 PN16

Service Life

50 years for normal use

Delivery Time

Stock available for regular sizes

Production Lead Time

7-10 days for a 20ft container, 10-15 days for a 40ft container.

Loading Port

Ningbo or Shanghai, China


Minimum Order Quantity

Negotiation

Price

Negotiation

Packaging Details

PP woven bag

Delivery Time

Within 7 days

Payment Terms

30% deposit for producing, 70% balance to be paid before shipping.

Supply Ability

100Tons/ Month


Product Name

Specification(mm)

SDR21

SDR17

SDR13.6

SDR11

HDPE Butt Fusion Flange Adapter (HDPE Flange Adapter)

50

63

75

90

110

125

140

160

200

225

250

280

315

355

400

450

500

560

630

710

800

900

1000

1200
