400 Hydraulic semi-automatic heat fusion welding machine Custom

Home / Products / Welding Machine / Hydraulic butt Fusion Welding Machine / 400 Hydraulic semi-automatic heat fusion welding machine
  • 400 Hydraulic semi-automatic heat fusion welding machine
  • 400 Hydraulic semi-automatic heat fusion welding machine
  • 400 Hydraulic semi-automatic heat fusion welding machine
  • 400 Hydraulic semi-automatic heat fusion welding machine
Hydraulic butt Fusion Welding Machine

400 Hydraulic semi-automatic heat fusion welding machine

Features:
Assembled by the frame, hydraulic controller, planning tool, support of planning tool & the heating plate, the heating plate and the optional accessories;
Independent temperature control of the heating plate and PTFE surface coating;
Heating control with precision and stable electronic temperature control device, and provide the deviation correction function;
Electric planning tool;
Main body of Frame is Aluminium alloy. 45 ° inclined design, simple structure and easy to use;
Hydraulic control frame, more powerful and low starting pressure to make the small diameter pipe welding is more reliable;
Welding position can be transformed. Convenient to weld all kinds of pipe fittings;
Independent dual channel timer can record the two periods of heat and cooling, timing alarm over to convenient the user;
Big dial, high-precision shock pressure, table read mathematical clearly
CONTACT US
  • description
  • application
  • message to us
  • FAQ
Specification and model GF-400
Welding range(mm) 250,280,315,355,400
Heating plate power 5kw/380v
Milling cutter power 1.1kw/380v
Hydraulic station power 1.1kw/380v
N.W 288kg
G.W 348kg
Total volume (m³) 1.71
Package Size(cm)
Weight(kg)
Frame 82*74*100 136kg
Heating plate 132*79*88 161kg
Milling cutter
Basket
Hydraulic station 67*53*52 51kg
